Graco 562949 - MODEL 25 PUMP,ASSY,.187 DIA

Graco 562949 – MODEL 25 PUMP,ASSY,.187 DIA

Part Number: 562949

Manzel® Model 25 Compressor Lubricator Replacement Pump, 3/16 in (4.8 mm), 1000 PSI (69 BAR)

Description

Manzel® Model 25 Compressor Lubricator Replacement Pump, 3/16 in (4.8 mm), 1000 PSI (69 BAR)

Compatible material	Oil
Drive option	Direct Rotary
Lubricator feed type	Force Feed
Manufacturer	Graco
Maximum drive speed	60 RPM
Maximum fluid viscosity	5000 SUS
Maximum working pressure	69 BAR / 6900 KPA / MPA / 1000 PSI
Minimum drive speed	3 RPM
Minimum fluid viscosity	100 SUS
Model	Manzel
Outlet size	1/4 IN / 0.635 CM / 6.35 MM
Outlet thread gender	Female
Outlet thread type	NPS
Overall depth	25.59 IN / 65 CM / 650 MM
Overall height	8.50 IN / 21.6 CM / 215.9 MM
Overall width	15.24 CM / 6 IN / 152.4 MM
Primary UOM Code	EA
Pump size	0.5 CM / 3/16 IN / 5 mm
Reservoir material	Steel
Series	Model 25
UPC Code	633955349476
Wetted material	Fluoroelastomer;Gray Iron;Carbon Steel;Alloy Steel;Stainless Steel
Max num drops per stroke	6 Drops
Min num of drops per stroke	0.17 Drops
Piston size	0.47 CM / 0.19 IN / 4.7 MM
Product_type	Box Lubricator
