Description
Simple, rugged, compact differential pressure gauge
Ranges from 0 psid to 5 psid through 0 psid to 110 psid
Engineered plastic gauge case
Clear anodized Aluminum and 316 Stainless Steel wetted parts
Noshok
25-1012-P30-A2P-1
Differential Pressure Gauge
Simple, rugged, compact differential pressure gauge
Ranges from 0 psid to 5 psid through 0 psid to 110 psid
Engineered plastic gauge case
Clear anodized Aluminum and 316 Stainless Steel wetted parts
Additional information
| Manufacturer | Noshok |
|---|---|
| Connection Type | Female National Pipe Thread (FNPT) |
| Material | Engineered Plastic |
| Gauge size | 2-1/2 in, 6 |
| Measuring element | 316 Stainless Steel and Ceramic Piston/Magnet |
