Pressure Transducer
0 to 6,000 psig, 0.25% Accuracy (Best Fit Straight Line (BFSL)), 0 to 10 Vdc Output, Society of Automotive Engineers (SAE) J1926-1:7/16-20 Pressure Transducer with DIN EN 175301-803 Form C Electrical Connection
Ranges from vacuum to 0 psig to 15,000 psig; absolute ranges from 0 psia to 15 psia through 0 psia to 300 psia
Voltage output
316 and 17-4PH Stainless Steel wetted parts
CE compliant to suppress RFI, EMI and ESD
0 to 6,000 psig, 0.25% Accuracy (Best Fit Straight Line (BFSL)), 0 to 10 Vdc Output, Society of Automotive Engineers (SAE) J1926-1:7/16-20 Pressure Transducer with DIN EN 175301-803 Form C Electrical Connection
Ranges from vacuum to 0 psig to 15,000 psig; absolute ranges from 0 psia to 15 psia through 0 psia to 300 psia
Voltage output
316 and 17-4PH Stainless Steel wetted parts
CE compliant to suppress RFI, EMI and ESD
| Manufacturer | Noshok |
|---|---|
| Connection Type | Society of Automotive Engineers (SAE) J1926-1:7/16-20 |
| Housing Material | 316 Stainless Steel |
| Output Signal | 0 Vdc to 10 Vdc, 3-Wire |
| Adjustment | ±10% full scale for zero and span |
| Ambient temperature range | -40 to 185 ºF |
| Connection material | 316 Stainless Steel |
