Donaldson | P560401. MUFFLER, ROUND STYLE 3/STYLE 4

Donaldson

Donaldson | P560401. MUFFLER, ROUND STYLE 3/STYLE 4

Part Number: P560401

Muffler, Round Style 3/Style 4

SKU: P560401 Category: Exhaust

Description
Additional information

Description

Muffler, Round Style 3/Style 4

Additional information

Attenuation hr	18 DBA
Attenuation lr	12 DBA
Body diameter maximum	300.7 MM / 11.84 IN
Body length	654 MM / 25.75 IN
Filter style	Style 3/Style 4
Inlet diameter	127.64 MM / 5.03 IN
Manufacturer	Donaldson
Outlet diameter	127.64 MM / 5.03 IN
Overall length	804.9 MM / 31.69 IN
Rated flow hr	69.3 CMM
Rated flow lr	49.9 CMM
Rated flow mr	69.3 CMM
Back pressure low range	25 MM HG / 0.98 IN HG
Back pressure mid range	51 MM HG / 2.01 IN HG
Back pressure high range	51 MM HG / 2.01 IN HG
Inlet clock position	6:00
