Pressure Transducer
0 to 100,000 psig, 0.25% Accuracy (Best Fit Straight Line (BFSL)), 4 to 20 mA Output, 9/16-18 Female High Pressure Transducer with DIN EN 175301-803 Form A Electrical Connection
Vacuum ranges through 0 psig to 145,000 psig; absolute ranges from 0 psia to 15 psia through 0 psia to 300 psia
Current and voltage outputs available
316 and 17-4PH Stainless Steel wetted parts
0 to 100,000 psig, 0.25% Accuracy (Best Fit Straight Line (BFSL)), 4 to 20 mA Output, 9/16-18 Female High Pressure Transducer with DIN EN 175301-803 Form A Electrical Connection
Vacuum ranges through 0 psig to 145,000 psig; absolute ranges from 0 psia to 15 psia through 0 psia to 300 psia
Current and voltage outputs available
316 and 17-4PH Stainless Steel wetted parts
| Manufacturer | Noshok |
|---|---|
| Housing Material | 316 Stainless Steel |
| Output Signal | 4 mA to 20 mA, 2-Wire |
| Adjustment | ±10% full scale for zero and span |
| Ambient temperature range | -15 to 175 ºF |
| Connection material | 316 Stainless Steel |
