Part Number: 46632930
RECOMMENDED FOR: Fuel tank filler applications to provide a flexible connector between fuel tank and fill pipe. Suitable for fill applications on automobiles, trucks, buses and other similar applications where exceptionally flexible hose is required.
RECOMMENDED FOR: Fuel tank filler applications to provide a flexible connector between fuel tank and fill pipe. Suitable for fill applications on automobiles, trucks, buses and other similar applications where exceptionally flexible hose is required.
| Manufacturer | Gates |
|---|---|
| Cover color | Black |
| Cover material | Chloroprene – Type A |
| Length | 10 ft / 3 m |
| Max temperature | 100 C / 212 F |
| Min bend radius | 7 in / 178 mm |
| Min order quantity | 40 |
| Min temperature | -40 C / -40 F |
| Reinforcement | Multi-ply, synthetic textile, dual wire helix |
| Tube material | Nitrile – Type C |
| UOM | FT |
| Working pressure | 20 psi / 1.4 bar |
| Hose ID | 0.1071 in / 12.1028 mm |
| Hose OD | 0.1115 in / 23.103 mm |
| Tube characteristics | Medium oil resistance |
| Cover characteristic | Corrugated |
| Vacuum (Hg) | 30 in / 762 mm |
| SAE specifications | 30R5 |
| Cover standard | ARPM Class C |
| Tube standard | ARPM Class B |
| Second Name | 46632930 |
| Product line | 4663K Fuel Fill Hose |
