Description
Manzel® MB118 Series Lubricator – 4 Pint (1.9 Liter) Reservoir (4 Pump Stations Max), No Pumps Installed, 118:1 drive on right hand end
Part Number: 24W633
Manzel® MB118 Series Lubricator – 4 Pint (1.9 Liter) Reservoir (4 Pump Stations Max), No Pumps Installed, 118:1 drive on right hand end
Manzel® MB118 Series Lubricator – 4 Pint (1.9 Liter) Reservoir (4 Pump Stations Max), No Pumps Installed, 118:1 drive on right hand end
| Manufacturer | Graco |
|---|---|
| Primary application | MB118 is the right size for triplend quintuplex mud pump applications. |
| Primary UOM Code | EA |
| UPC Code | 755652280026 |
| Model | Manzel |
| Compatible material | Oil |
| Drive option | Internal Gear Reduction |
| Lubricator gear ratio | 118:01:00 |
| Max drive speed | 1800 RPM |
| Max fluid viscosity | 5000 SUS |
| Max number of pump stations | 4 |
| Max working pressure | 517.1 BAR / 51710 KPA / MPA / 7500 PSI |
| Minimum fluid viscosity | 80 SUS |
| Overall depth | 14.25 IN / 36.2 CM / 362 MM |
| Overall width | 13.97 CM / 5.5 IN / 139.7 MM |
| Product type | Box Lubricator |
| Reservoir material | Steel |
| Wetted material | Carbon Steel;Nylon;Fluoroelastomer;Cork;Brass;Aluminum |
| Max number of strokes | 15 spm |
| Max reservoir capacity | 0.5 GAL / 1.9 L / 4 PT /2 QT |
| Number of pumps | 0 |
